OSCILLOSCOPES
  • Overviews
    • Tektronix has a great document explaining the basics of the oscilloscope. Check it out here.

    • NA5N (Paul Harden) has an article entitled Oscilloscopes - Basic Use and Measurements that you can read here.

    • KENWOOD CS-5170 OSCILLOSCOPE
    CS5170 Two channel 100 MHz 'scope.

    HEWLETT-PACKARD 1742A OSCILLOSCOPE
    Two channel 100 MHz delayed sweep oscilloscope.

    HEWLETT-PACKARD 54616B OSCILLOSCOPE
    CS5170 Two channel 500 MHz 2 gigasamples per second oscilloscope.

    HEWLETT-PACKARD 54645D OSCILLOSCOPE
    CS5170 Two channel 100 MHz 200 megasamples per second oscilloscope, circa 1998.

    AN/USM-281A
    Navy Scope Front Navy Scope Label Navy version of the Hewlett-Packard 180F Ruggedized Oscilloscope, circa 1969.
